Building Material R-Values

Tighthouse Product image

An Interesting video on common building envelope issues, in Australia.

There are many websites on the internet which have Imperial Building Material R-value numbers, but not so many with Metric R-value numbers.  The following table is in Metric form.  K·m2/W

Click here to go to our Calculator to understand the real R-value of a ceiling system or wall system with gaps in the insulation.

recessed lighting missing insulation1

It can get confusing when you see Imperial R-values in the USA, which is very different to Australia and Europe who use the metric system.

Included in this table also will be known/tested leakage rates of different building materials installed in a continuous manner, articulated in a permeability rate.

R-value Listing of Common Products

These are Generalised R-value numbers for many types of building materials. These values may not be accurate for your building material. Consult your manufacturer for more accurate data if required.
MaterialThicknessR-Value m2K/WPermeability@50PaNotes
Air Film Interior Wall.14
Air Film Interior Ceiling.14
Air Film Exterior.04
Air Gap1.2cm - 10cm.176
Building Sheets
Plaster10mm - 13mm.07 - .077
Plaster18mm.08
Chipboard18mm.17
Plywood12mm.1
Plywood25mm.22
Timber25mm.12 - .25
Cement Sheet8mm.005
Insulation Materials
Downlight/Loft Mitt.62
Sarking Foil (sisalation).2
Earthwool200mm4.0
Earthwool100mm2.0
Polyurethane foam-a-fill25mm1.1
Rockwool200mm4.5
Rockwool100mm2.7
Polyester200mm3.5
Polyester90mm1.5
Polystyrene25mm.88Very poor sound proofing
Common Brick90mm.05 - .07
Mud Brick300mm.27
Concrete100mm.07
Granite25mm.009
Sandstone.014
Glass6mm.006
Concrete tiles50mm.05
Terracotta Tiles6mm.004
Colourbond1.2mm0
Insulated roofing panel100mm2.75
Insulated roofing panel75mm2.11
Insulated roofing panel50mm1.48
vinyl3mm.009
rubber3mm.009
Hardwood.12
Carpet Polyester10mm.167
Carpet Wool10mm.38
Tiles.009
Carpet + Rubber Underlay.51
Solid Core Door44mm.38
Single Pane window6mm Glass.16
Double Glazed 4mm glass6mm gap.317Centre of Glass
Double Glazed 6mm glass6mm gap.32Centre of Glass
Double Glazed 4mm glass12mm gap.37Centre of Glass
Double Glazed 4mm glass16mm gap.37Centre of Glass
Triple Glazing 4mm glass6mm gap.46Centre of Glass
Triple Glazing 4mm glass12mm gap.56Centre of Glass
Double Glazing low-e 6mm and internal 4mm12mm gap.58Centre of Glass
Triple Glazing 4mm glass with low-e12mm gap.82Centre of Glass
Double glazed 4mm - 4mm10mm gap.36Centre of Glass
Double glazed 6mm - 4mm10mm gap.36Centre of Glass
Double glazed 4mm - 4mm - low-e10mm gap.55Centre of Glass
Double glazed 6mm - 4mm - low-e10mm gap.55Centre of Glass
Hebel Panel75mm.59
Double glazed Viridian 4mm and 4mm6mm gap.32Centre of Glass
Double glazing 4mm - 4mm with low-e on inside only6mm gap.42Centre of Glass
KNAUF ClimaFoam XPS Board30mm1.1
KNAUF ClimaFoam XPS Board50mm1.8
Open Cell Spray Foam icynene50mm1.3
Closed Cell Spray Foam icynene50mm2.16
Double glazed 4mm - 4mm20mm gap.36Centre of Glass
Double glazed 4mm- 4mm30mm gap.358Centre of Glass
High Performance Laminate Glass + Low-E8.37mm.29Centre of Glass
Viridian - WOW
Poor Performance Laminate Glass- no Low-E6mm0.175Centre of Glass
Spray Foam Closed Cell (Spray Foam can be variable - depending on contractor)100mm4.8~
Spray Foam Open Cell (Spray Foam can be variable - depending on contractor)100mm2.64~
Suntuf Twin Wall Polycarbonate corflute10mm.34
Pink Batts HD195mm4.1

Please contact us if you would like to include the R-value of any other products into this table.
